SVBONY SV305 1.25 inch Astronomical Camera for Planetary Photography

SVBONY SV305: 1.25 inch Astronomy Camera for Planetary Photography

The SVBONY SV305 astronomy camera uses an extremely sensitive BSI (Back-Side Illuminated) CMOS sensor, the IMX290. This sensor offers very high sensitivity and very low read noise (0.7 e-) in the visible light and near-infrared regions, making it an ideal choice for industrial applications.

Features

• Sensor: 1/2.8" CMOS SONY IMX290
• Pixel Size: 2.9 x 2.9 μm
• Resolution: 2 megapixels (1920x1080)
• Shutter: Electronic
• Maximum Frame Rate: 130 fps (320*240)
• Video Encoding: RAW
• ADC: 12 bits
• ROI Support: Any ROI area
• Camera Buffer: 128M DDR buffer
• Optical Window: IR650 Glass
• Interface: USB 2.0
• Alloy:

Compatibility and Performance

The SV305 camera is compatible with Windows, Linux, Raspberry Pi, and Mac OS systems. It supports long exposures of up to 30 minutes and offers three frame rate speeds: high speed, medium speed, and low speed. The power consumption is 200 mA @ 5 V.
